Benefit
Enhanced quality
High Performance
Enhanced Quality
Powerful Functionality
Enhanced Quality
High Accuracy
Saving labor cost
Strong Computing Power
Saving labor cost
Data Processing Library
Conserved space
Four Network Ports
High Performance
Computational speeds of 250 μs (8 axes), 500 μs (32 axes), and 4 ms (256 axes)
Powerful Functionality
Compatible with manipulators, electronic cams, and electronic gears
High Accuracy
±40 μs jitter
Strong Computing Power
Intel Core i7, 128 GB SSD, and 4 GB DDR
Data Processing Library
Big data processing, file processing, and production line data collection and processing
Abundant Data Exchange Channels
OPC UA, EtherNet/IP and other industrial buses
Four Network Ports
Two EtherCAT ports, compatible with both fast-response real-time axis control and PTP control, facilitating ring network building
Two Ethernet ports with different IP segments, one for networking between devices and the other for connection to the information layer, facilitating isolation for security
Two Ethernet ports with different IP segments, one for networking between devices and the other for connection to the information layer, facilitating isolation for security
